Single Digital Pressure Gauge with sight glass for Air Conditioning
Charging
Product Introduction:
The pressure flow and the controls of the cold media group for the
injection of refrigerant, It is widely used in the area of
hydraulic and atmospheric pressure as refrigerant equipments, Air
Conditioner and refrigerant tools, pressure tools, vacuum
equipments, pneumatic equipments, etc. This gauge has no moving
parts, has long service life, high precision, good long-time
stability.
Features:
1. Brass block body.
2. Unique streamline anti-collision design
3. Extra large knobs for easy grip
4. Excellent vacuum characteristics
5. One full turn open/close valve
6. The large scale mark and high contrast color design makes the
way of reading data easier.
7. Compatible with : R134A R22 R12 R502 R410A R404 R1234YF.
8. Every manifold is individually tested for reliability before
packing
9. Pure copper core as per the International Standard 1.6
precision.
Product Data:
| Product Name | Manifold Gauge Set HVAC refrigeration system Charging |
| Body Material | Brass & Auminum |
| Handle Material | The plastic & aluminum |
| Refrigerant | R134A R22 R12 R502 R410A R404 R1234YF |
| Maximum Overload Pressure | 75bar, 1087psi, 7.5 MPa, 76.5kgf/cm², 7500KPa |
| Pressure Range | 0~50bar, 0~720psi, 0~5MPa, 0~51kgf/cm², 0~5000KPa(Relative
pressure) |
| Vacuum Range | -29.9~0inHg |
| Resolution | 0.1bar, 0.1psi, 0.001MPa, 0.1kgf/cm², 1Kpa, 0.1inHg |
| Connection | 1/4SAE |
| Operating Temperature | -10~50℃, 14~122°F |
| Storage Temperature | -20~60℃, -4~140°F |
FAQ
Q1: Can you provide sample?
A1: Yes, we can send the sample for free but not pay the sample
freight.
Q2: What kind of Certificate do you have?
A2: Our products have the ISO9001,ISO17025,ISO14001,ISO14001,ISO
45001 SCOC.
Q3: How are orders packed?
A3: Normally boxes packed inside an outer carton and placed on a
wooden pallet.
Q4: How long is the warranty of your products?
A4: We provide one year after-sale guarantee.
Q5: Can you produce the products labeled with the client's brand?
A5: OEM, ODM are supported.
Q6: What kind of payment terms do you accept?
A6: Normally 30% T/T in advance as deposit, balance paid before
shipment.
